| Specification | |
| Table | 35.4″ x 18″ |
| Longitudinal travel (X-axis) | 31.5″ |
| Cross travel (Y-axis) | 20″ |
| Vertical travel (Z axis) | 24″ |
| Spindle nose to table top (D) | 5.5″ to 29.5″ |
| Spindle center to column front surface | 23.1″ |
| Spindle taper | BT40 / CAT40 |
| Spindle speed | 8000 rpm |
| Load capacity | 1320 lbs |
| T-slot | 0.7″ x 4 x 4.7″ |
| Motor | |
| Spindle motor/max torque | 10 HP |
| Power requirement | 19 KVA |
| Pneumatic tank requirement (min) | 5 ~ 8 (5) kg/cm^2 |
| Coolant tank capacity | 63.4 gal (1 hp) |
| Feed Rate | |
| Rapid feed rate | X/Y/Z: 640/640/480 ipm |
| Cutting feed rate | 300 ipm |
| Automatic Tool Changer | |
| No, of tools | 16 tools atc armless |
| Max tool diameter | Ø 3.1″ |
| Max tool length | 11.8″ |
| Max tool weight | 15.4 lbs |
| Dimension & Weight | |
| Length x width x height | 125″ x 92″ x 99″ |
| Net weight | 11400 lbs |
